LGX Lite Mount

The Mosquito® Hotend ALU Mount Plate is used to attach your Mosquito® Hotend or Mosquito® Magnum Hotend directly to the LGX Lite Extruder. The Copperhead® Groove Mount Hotend PA12 Mount Set is used to attach your Copperhead® Groove Mount Hotend to the LGX Lite Extruder.



Mosquito® Hotend ALU Mount Plate

Material Specifications

This LGX Lite mount plate has been machined in Aluminum and has been bead blasted.

Installation Instructions

To install this Bondtech LGX mount, face the flat surface against the LGX Lite‘s bottom and tighten it with the 3x M3x8 countersunk screws. Then, fit the PTFE tube and attach the Mosquito Hotend to the adapter from below using 2x M2.5 screws.



Copperhead® Groove Mount Hotend PA12 Mount

Material Specifications

This mount has been laser sintered in Polyamide 12 and has been bead blasted. It is supplied with a wax protective coating to lower sensitivity to moisture and grease, while remaining fully functional.

This product is manufactured by Bondtech.
